carbon steel pipe tube are divided into seamless steel pipes and welded steel pipes. seamless steel pipeis made of perforated whole round steel, and the steel pipe without weld seam on the surface is called seamless steel pipe. According to the production method, seamless steel pipes can be divided into hot-rolled seamless steel pipes, cold-rolled seamless steel pipes, cold-drawn seamless steel pipes, extruded seamless steel pipes, and pipe jacking. According to the cross-sectional shape, the seamless steel pipe is divided into two types: round and special-shaped. The maximum diameter is 900mm and the minimum diameter is 4mm. According to different uses, there are thick-walled seamless steel pipes and thin-walled seamless steel pipes.
Carbon steel pipe with hollow section, a large number of pipeline used for conveying fluid, such as oil, natural gas, gas, water and some solid materials pipeline. It is widely used in the manufacture of structural and mechanical parts, such as oil drill pipe, automobile transmission shaft,bicycle frame and steel scaffolding used in construction.
Welded steel pipe,also known as welded pipe, is a steel pipe made of steel plate or strip after crimping and welding, generally 6 meters. Welded steel pipe production process is simple, high production efficiency, variety specifications, less investment in equipment, but the general strength is lower than seamless steel pipe.Straight seam welded pipe, steel pipe made of hot or cold rolled steel plate or steel strip coil welding, straight seam welded pipe on welding equipment are called straight seam welded pipe.
① Seamless steel pipe
1.Grade:Q195/Q215/Q235/Q345/S235JR/GRB-D/STK500
2.Size: diemeter is from 21.5 in to406.4 mm,the thickness is from 0.6mmto 20mm the length is from m to 12m
3.Standard:SY/T5037-2000.GB/T9711.1-1997,GB/T9711.2API-5L，SY/T5040-92,ASTMA53A106，DIN1626,DIN1629,DIN2448JIS G3452JIS G3454JIS G3455JIS G3456JIS G3457JIS G3461
② welded pipe
1.Grade:Q195/Q215/Q235/Q345/S235JR/GRB-D/STK500
2.Size: diemeter is from 21.5 in to406.4 mm,the thickness is from 0.6mmto 20mm ,the length is from 1m to 12m
3.Standard:SY/T5037-2000.GB/T9711.1-1997，GB/T9711.2API-5L.SY/T5040-92 ASTMA53A106.DIN1626DIN1629DIN2448.JIS G3452JIS G3454JIS G3455JIS G3456JIS G3457JIS G3461
| Product Name | carbon steel pipe tube |
| Standard | ASTM A106, ASTM A53, API 5L Gr.B, DIN17175,DIN1629 |
| Steel Grade | API 5L: GR B,X42,X46, X56, X60, X65,X70 ASTM A53: GR A, GR B, GR C EN: S275, S275JR, S355JRH, S355J2H GB: Q195, Q215, Q235, Q345, L175, L210, L245, L320, L360-L555 |
| Materials | 10#,20#,45#,Q235,Q345,Q195,Q215,Q345C,Q345A ASTM A53A/A53B/ A178C/A106B API5L ST37,ST37-2,DIN 1629 ST35, ST45,DIN 17175 ST35.8,DIN 17175 19Mn5 16Mn,Q345B,T1,T2,T5,T9,T11,T12,T22,T91,T92,P1,P2,P5,P9,P11,P12,P22,P91,P92, 15CrMO,Cr5Mo,10CrMo910,12CrMo,13CrMo44,30CrMo,A333 GR.1,GR.3,GR.6,GR.7 Gr.B,X42,X46,X52,X60,X65,X70,X80,X100 |
| Technique | Hot rolled / cold rolled |
| size | Wall Thickness:4mm-70mm Out Diamete:1mm-610mm |
| Length | 5.8~12.0 m or as customized |
| Surface Treatment | Prime quality (bared, oiled, color paint, 3LPE, or other anti-corrosive treatment) |
| Certification | CE, ISO, SGS,ETC |
| Packing | Waterproof paper, and steel strip packed. Standard Export Seaworthy Package. Suit forall kinds of transport, or as required |
| MOQ | 5 tons |
The smelting of carbon steel is usually carried out in converter and open hearth. Converters generally smelt ordinary carbon steel, while open furnaces smelt all kinds of high-quality steel. The technology of oxygen top blow converter is developing rapidly and it can replace open hearth furnace. The refined liquid steel is injected into the ingot mold to obtain various ingot. After the ingot is forged or rolled, it is processed into plates, strips, bars, and sections of various sectional shapes. Carbon steel is usually used directly in the hot rolled state. When used for manufacturing tools and various machine parts, it needs to be heat treated according to the requirements of use; As for steel castings, most of them are heat-treated.
| Chemical Properties % | |||||||||
| Grade A | |||||||||
| C | Mn | P | S | Si | Cr | Cu | Mo | Ni | V |
| 0.25 | 0.27-0.93 | 0.035 | 0.035 | 0.1 | 0.4 | 0.4 | 0.15 | 0.4 | 0.08 |
| Grade B | |||||||||
| C | Mn | P | S | Si | Cr | Cu | Mo | Ni | V |
| 0.3 | 0.29-1.06 | 0.035 | 0.035 | 0.1 | 0.4 | 0.4 | 0.15 | 0.4 | 0.08 |
| Grade C | |||||||||
| C | Mn | P | S | Si | Cr | Cu | Mo | Ni | V |
| 0.35 | 0.29-1.06 | 0.035 | 0.035 | 0.1 | 0.4 | 0.4 | 0.15 | 0.4 | 0.08 |
